StackShot 3X Pan-Tilt Field Kit
As low as $2,089.00
The Pan / Tilt Field Kit includes everything you will need to take your StackShot 3X controller and Pan / Tilt System into the field.
What's Included:1 x StackShot 3X Controller
2 x Cognisys Rotary Tables
2 x 0.25m - Locking Motor Cables (not shown)
1 x 2A AC adapter
1 x Pan Tilt Bracket set (including hardware and Allen keys)
2 x Neoprene Bags for Rotary Tables
1 x Li-Ion Battery Kit - 5200mAHr Version
1 x Controller Carrier Kit
The Controller Carrier Kit can be attached to the tilt upright but is shown attached to a Wimberley P-20 Arca Plate mounted to the bottom of the rotary table. Arca Plates, Clamps, and Tripod shown in images not included.
StackShot 3X - Focus Stacking and so much more.
Why purchase a Giga-pixel scanner, an automated turntable, and a panoramic head for time lapse separately when you can purchase a StackShot 3X system and use the same components to achieve all of this. StackShot 3X is a modular system with incredible flexibility. It is the next generation StackShot controller featuring 2 additional stepper motor controllers to allow complete 3 axis motion control. It is equipped with a touch screen user interface with haptic feedback making number entry quick and easy. You will also find USB and Wi-Fi on the StackShot 3X to allow control with your computer. If you are interested in the differences between this controller and the original StackShot visit our comparison page. So what applications are possible with this 3 axis controller?
- USB port for computer control and updating firmware
- Wi-Fi (802.11 a/b/g/n) enabled for wireless connectivity to your computer or our remote
- Controls one or two Rotary Tables, the StackShot 3X Slider, and/or the StackShot Macro Rails
- Capacitive touch screen full color display with haptic feedback for easy control
- All timing parameters for motion and shutter control are completely user configurable
- Durable extruded aluminum housing
- Adjustable motor torque - turn down the torque to save battery life or run small stepper motors
- LCD Power Save - perfect for nighttime photography, or just to save on battery life
- Dedicated modes for stacking, panoramas, shoot-move-shoot, and continuous motion control
- Configurable settle time in between captures
- Capture multiple photos at each step (exposure bracketing or mirror lockup)
- Preview options to examine your framing and setup
- Optional battery power for field shooting, operates at 12-24VDC
- User presets - Save your different setups and recall them as needed
- Change the lighting or exposure and run your last stack or motion profile with a single button press
- Dragon Frame compatible
- Helicon Focus and Zerene Stacker compatible (X-axis only)
- Compatible with existing StopShot/StackShot shutter cables or any shutter cable equipped with a 3.5 mm plug
| Specifications | MIN | NOM | MAX | UNITS |
| Input Voltage | 12 | 12 | 24 | Vdc |
| Input Current (12Vdc in) | - | 150 | 6000 | mAdc |
| Input Current–Power-saving modes active | - | 50 | - | mAdc |
| Shutter Output Current Sink | - | - | 1 | Adc |
| Operating Temperature | -20 | 25 | 70 | C |
| -4 | 77 | 158 | F |
StackShot 3X Resources
Owner's Manual
Firmware Updates
3X Computer App
Computer App Notes
The StackShot 3X application is written in Java, and you will need to make certain you have Oracle's Java installed. The StackShot 3X Application will let you know if you need to update your version of Java. You can find the latest version here:
